PRODUCT INFORMATION
- Description
- men's, e-bike, 21", sage green
- Item No.
- 223452
- Brand
- CTM
- Model
- Areon e-Xpert 29"
- UNI
- 223.452
- Product information
Frame: alu 6061, rear travel 135 mm, XL, 21"
Fork: Rock Shox Recon silver RL, SA, 140 mm, boostTM 15 x 110 axle
Breaks: Shimano MT200/SMRT10M
Shifters: Shimano Deore SL-M5100/11sp.
Rear derailleur: Shimano Deore RD-M5100
Speed: 11 speeds
Weight: 26.2 kg
Shock: Rock Shox Deluxe Select+ RT (210 x 55)
Cassette: CTM CS11, 11/50
Crankset: Bafang 38T, 170 mm
Rims: WTB ST i29 TCS 2.0 29", 32H
Tyres: WTB Trail Boss 29 x 2.4" Comp
Hubs: Shimano MT400 boost / 32H
Pedals: VPE-527
Chain: KMC X11e 128L
Stem: CTM ASM03 45 mm
Handlebars: CTM rise bar, 31.8, 760 mm
Headset: NECO H156
Saddle: CTM FLAT
Seatpost: EXA Form KSP900, 150 mm
Engine: Bafang M500 / 250W / Torgue 95 Nm, Weight: 3.3 kg
Battery: CTM IGB 770Wh / 48V / 16Ah
Range 50 km to 120 km, charging to max. capacity ~ 6 hours
